Bake hardening steel | HX180BD - HX340BD
Choose your bake hardening steel here in grades HX180BD, HX220BD, HX260BD, HX300BD and HX340BD.
The experts at our locations are happy to advise you. We look forward to hearing from you.
Properties of bake hardening steel HX180BD - HX340BD | DIN EN 10 346
Steel type
Short designation | VDA239-100* | Surface finish | Material number |
HX180BD | CR180BH | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 1.0914 |
HX220BD | CR210BH | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 1.0919 |
HX260BD | CR240BH | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 1.0924 |
HX300BD | - | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 1.0930 |
HX340BD | - | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 1.0945 |
Mechanical properties (transverse)
Short designation | Proof stress Rp0.21) MPa | Tensile strength Rm MPa | Elongation at fracture A802)3) % | Anisotropy r90 3)4)5) min. | Strain hardening exponent n905) min. | Bake hardening index BH2 min. |
HX180BD | 180-240 | 290-360 | 34 | 1.5 | 0.16 | 30 |
HX220BD | 220-280 | 320-400 | 32 | 1.2 | 0.15 | 30 |
HX260BD | 260-320 | 360-440 | 28 | - | - | 30 |
HX300BD | 300-360 | 400-480 | 26 | - | - | 30 |
HX340BD | 340-400 | 440-520 | 24 | - | - | 30 |
Chemical composition (heat analysis)
Short designation | Percentage by weight % max. | |||||||
C | Si | Mn | P | S | AI min. | Nb | Ti | |
HX180BD | 0.06 | 0.50 | 0.70 | 0.060 | 0.025 | 0.015 | 0.09 | 0.12 |
HX220BD | 0.08 | 0.50 | 0.70 | 0.085 | 0.025 | 0.015 | 0.09 | 0.12 |
HX260BD | 0.10 | 0.50 | 1.00 | 0.10 | 0.030 | 0.010 | 0.09 | 0.12 |
HX300BD | 0.11 | 0.50 | 0.80 | 0.12 | 0.025 | 0.010 | 0.09 | 0.12 |
HX340BD | 0.11 | 0.50 | 0.80 | 0.12 | 0.025 | 0.010 | 0.09 | 0.12 |
Your product of choice: HX180BD - HX340BD
1) Where the yield strength is defined, the respective values shall apply to the lower yield strength (ReL).
2) Depending on the product thickness, the minimum values of elongation at fracture are reduced as follows: 0.50 mm < t < 0.70 mm (minus 2 units), 0.35 mm < t < 0.50 mm (minus 4 units), and t < 0,35 mm (minus 7 units).
3) For AS, AZ, ZF and ZM coatings, the minimum A80 value is reduced by 2 units and the minimum r90 value by 0.2.
4) For product thicknesses of 1.5 mm < t < 2 mm, the minimum r90 value is reduced by 0.2, and for t ≥ 2 mm by 0.4.
5) Depending on the product thickness, the minimum r90 value is reduced as follows: 0.50 mm < t < 0.70 mm by 0.2; 0.35 mm < t < 0.50 mm by 0.4, and t < 0.35 mm by 0.6. Also depending on the product thickness, the minimum n90 value is reduced as follows: 0.50 mm < t < 0.70 mm by 0.01; 0.35 mm < t < 0.50 mm by 0.03, and t < 0.35 mm by 0.04.
*Comparative grade, therefore minor deviations from DIN EN values possible
